Curtron SPD-20-AL-DBL-9684 96" x 84" Service-Pro Series 20 Swinging Door - CUSPD20ALDBL9684
The Curtron SPD-20-AL-DBL-9684 is designed specifically to increase customer and employee comfort. It does this by reducing the noise coming from the kitchen, stock rooms, warehouses, and other such areas while providing years of dependable service. The Service-Pro Door has an attractive design, engineered of .063" tempered aluminum with a satin anodized finish. It has two 9" x 14" clear windows. It does not come with a kickplate or bottom pin. The SPD-20-AL-DBL-9684 does, however, come with a hinged assembly and bottom pin. It has two 48" x 84" door panels.
Features
- (2) 48" x 84" door panels
- .063" tempered aluminum with satin anodized finish
- (2) 9" x 14" clear windows
- No kickplate / impact plate
- Hinged assembly and bottom pin
- Increases customer and employee comfort by reducing noise and providing years of dependable service
- Every Service-Pro door comes with the outstanding customer service and support of Curtron Products
- Attractive impact doors used in customer and back kitchen areas as well as in retail and industrial environments
- Creates a barrier between customers and kitchens, stock rooms, warehouses and more
Specifications
- Model: SPD-20-AL-DBL-9684
- Dimensions: 84" H x 96" W
- Approximate Weight: 196 lbs.
What our Experts Think
-
Large Double-Swing Opening: Provides a 96″ wide × 84″ high opening with two 48″ × 84″ panels, ideal for high-traffic zones like kitchens, service corridors, or back-of-house areas.
-
Light-Duty Aluminum Construction: Made with .063″ tempered aluminum and a satin-anodized finish, allowing easy swing for frequent personnel and light cart traffic.
-
Built-In Visibility Windows: Each panel includes a 9″ × 14″ clear acrylic window, improving safety by allowing sight-lines through the doorway.
-
Efficient Two-Way Traffic Flow: Double-panel design facilitates smooth two-way movement, reducing collisions and improving workflow.
-
Installation Considerations: Confirm that the rough opening accommodates 96″ width × 84″ height, allow sufficient swing clearance on both sides, and ensure wall/frame support is adequate.
Q&A
Q: What is the SPD‑20‑AL‑DBL‑9684 model?
A: A double‑leaf, double swing door from the Service‑Pro Series 20, designed for commercial traffic areas requiring a wide opening and frequent two‑way access.
Q: What are its dimensions and panel configuration?
A: Measures 96″ wide × 84″ high, with two 48″ × 84″ panels that swing both directions.
Q: What construction and material features does it include?
A: .063″ thick anodized aluminum panels, built‑in 9″ × 14″ clear windows, reinforced back spines, and standard swing hardware for durability.
Q: What types of environments is this door best suited for?
A: Ideal for restaurant kitchens, back‑of‑house entrances, convenience‑store service zones, or any commercial setting needing wide bidirectional flow and reliable access.
Q: What should installers verify before ordering and installing this door?
A: Ensure the rough opening is 96″ W × 84″ H, confirm swing clearance for both panels, verify frame and hardware support the aluminum construction, and select finish and vision panels appropriate for the facility.
Maintenance Tips
-
Clean the aluminum panels with a soft cloth and mild, non‑abrasive cleaner to maintain their satin anodized finish.
-
Inspect hinges, bottom pins, and fasteners periodically; make sure all components are secure and show no excessive wear.
-
Ensure both door leaves swing freely, align properly at the center, and close flush without rubbing or sticking.
-
Check the 9” × 14” viewing windows for cracks, clouding or seal failure.
-
Monitor panel surfaces for dents, corrosion or fatigue — especially in high traffic zones.
-
Lubricate hinge joints and pivot pins every 3–6 months to maintain smooth operation.
-
Twice a year perform a full inspection: clean hardware, tighten fasteners, test door under normal traffic, and replace any worn parts.
