Garland C36-NRM Garland Cuisine Gas Ranges - C36-NRM
Model C36-NRM | 108,000 BTU Natural or Propane Gas
Built for operators who need steak-house heat in a space-saving footprint, the Garland C36-NRM drops straight onto a stand, chef’s counter or refrigerated base and delivers a blazing 108,000 BTU of even, controllable cooking power. Six independently-valved burners, heavy cast-iron radiants and a fixed three-bar grate assembly combine to turn out beautifully branded proteins night after night while the all-stainless exterior shrugs off the grind of a high-volume kitchen.
Features
- Six 18,000 BTU cast-iron burners with individual controls every 6 inches (152 mm)
- Heavy cast-iron radiants for fast recovery and even searing temperatures
- Fixed, three-bar cast-iron grate assembly – reversible with one side featuring a grease trough
- Extra-large, front-mounted grease container for quick, mess-free clean-out
- All-stainless steel front, sides, stub back, burner box & front rail for maximum durability and easy wipe-down
- 1-1/4" NPT front gas manifold (optional rear connection, regulators, flex hose & shut-off valves available)
- Battery capable – align flush with other Cuisine Series modules for a custom cookline
- Field-convertible for stand, refrigerated or cabinet bases; flanged feet or swivel casters available
- Certified to CSA Flame, CSA Star & NSF standards
Specifications
| Width |
36" / 914 mm |
| Depth |
32-5/8" / 830 mm |
| Height (modular top) |
10" / 254 mm |
| Total Input |
108,000 BTU/h (Natural or Propane) |
| Burner Count / Rating |
6 × 18,000 BTU cast-iron |
| Gas Pressure (Manifold) |
6" WC (Natural) / 10" WC (Propane) |
| Standard Gas Connection |
1-1/4" NPT front |
| Clearances to Combustibles |
Sides 10" / 254 mm • Back 6" / 152 mm |
Accessories
- Stand with adjustable 6" stainless legs or 5" / 6" swivel casters (front brakes)
- Full-height or stub backguard extensions
- Rear gas connection kit (¾" NPT) with regulator & quick-disconnect flex hose
- Flanged feet kit for floor mounting
- 1/9-pan rail extension for mise en place
What our Experts Think
-
Powerful, Commercial-Grade Charbroiler: 36" modular charbroiler top with underfired broiler and cast-iron radiants delivers up to 108,000 BTU for consistent, high-heat cooking.
-
Durable, Easy-to-Clean Construction: Stainless-steel front, sides, stub-back, front rail, and burner box resist corrosion and withstand heavy daily use in commercial kitchens.
-
Even Heat Distribution & Reliable Performance: Fixed cast-iron grid assembly and cast-iron radiants ensure uniform heat — ideal for charbroiling meats, vegetables, or high-output cooking tasks.
-
Modular & Flexible Installation: Designed to integrate into larger kitchen line-ups, allowing easy expansion or combination with other units.
-
Commercial-Kitchen Ready: Built to meet professional standards for gas safety and sanitation, suitable for restaurants, catering, or institutional kitchens.
Q&A
Q: What type of equipment is the C36‑NRM?
A: A 36‑inch‑wide commercial gas modular unit combining a charbroiler with an under-fired broiler — built for heavy-duty cooking and grilling in professional kitchens.
Q: What is the total heat output?
A: Approximately 108,000 BTU, providing strong, consistent heat for searing and broiling.
Q: What cooking surfaces does it have?
A: Cast-iron charbroiler with cast-iron radiants and a fixed grate for even heat distribution and classic grill marks.
Q: What materials and construction quality does it have?
A: Stainless-steel front, sides, stub-back, front rail, and burner box for durability, corrosion resistance, and easy cleaning.
Q: What installation or layout considerations are needed?
A: Modular freestanding design, requiring proper commercial-grade gas supply and ventilation. Suitable for integration with other modular kitchen units.
Q: What type of kitchens is it intended for?
A: Commercial kitchens — restaurants, catering operations, institutional kitchens, or any high-demand food service operation needing reliable charbroiling or broiling.
Q: Is it suitable for residential use?
A: No. Its high BTU output, commercial design, and ventilation requirements make it appropriate only for professional kitchens.
Maintenance Tips
-
Clean cast-iron grates and surfaces daily: remove grates, wash with warm soapy water, dry thoroughly, and lightly oil to prevent rust.
-
Clear burner ports regularly using a wire or brush to remove grease or debris for proper gas flow and stable flames.
-
Wipe stainless steel exterior surfaces with mild detergent and a soft cloth; avoid abrasive cleaners to preserve finish.
-
Empty and clean drip trays and grease pans daily to reduce fire hazards and maintain hygiene.
-
Inspect gas connections, valves, and controls periodically for leaks or wear; ensure burners light properly and flames remain stable.
-
Allow the range to cool before deep cleaning and thoroughly dry all components to prevent rust or moisture damage.
