Laguna Tools Classic Combination Brush/Drum Sander - 19-38 - 219383

Laguna Tools Classic Combination Brush/Drum Sander - 19-38 - 219383

$2,207.99
Sale price  $2,207.99 Regular price  $2,943.99
Skip to product information
Laguna Tools Classic Combination Brush/Drum Sander - 19-38 - 219383
🌸 Offre de printemps : -15% uniquement cette semaine avec le code SPRINGBREAK
(offre valable jusqu'au 12 avril)

Laguna Tools Classic Combination Brush/Drum Sander - 19-38 - 219383

$2,207.99
Sale price  $2,207.99 Regular price  $2,943.99
In stock
⚡ Commandez avant 00h 00m 00s .
zephyrtrack livraison

Expédition 72h Protection 90j

zephyr android ios

Compatible Android ou iOS

4,7/5 sur 600+ avis

Payment methods
    Livraison et retours
    • Traitement et expédition : 1 à 3 jours après validation de votre commande
    • Livraison en France métropolitaine : 6 à 9 jours. Lien vers la politique
    • Retours : vous disposez de 30 jours après réception pour nous retourner vos articles. Lien vers la politique

    Laguna Tools Classic Combination Brush/Drum Sander - 19-38 - 219383

    Simplify sanding with a 19-38 Combination Brush/Drum Sander! Our exclusive technology allows you to drum sand and profile sand on the same machine! Interchangeable drum and brush heads allows for unlimited applications!

    Features

    We’ve addressed issues common with other drum sanders by adding five features that are exclusive to our 19-38 machines. No other drum sander on the market has these features!

    • Simple alignment feature Just one nut will adjust the conveyor to parallel the sanding head, making aligning the conveyor to the sanding head fast and easy
    • Indexed alignment setting Has an indexed alignment setting for narrow and wide stock. When sanding stock wider than 19″, the index lever will properly adjust the conveyor for flawless wide sanding
    • Easy height adjustments A thrust bearing below the handle and a nut positioned above prevents the drum from moving out of the set position while sanding. No backlash or slop in the height adjustment mechanism allowing easier and smoother height adjustments
    • Extra-wide conveyor to properly support stock over 19″ wide. The conveyor table is 22″ wide to add support to the work piece
    • Drum will never go “out of alignment” The drum carriage is bolted to the base, preventing any movement or alignment issues

    Additional Features

    • INTELLISAND™ Technology: Automatically adjusts conveyor speed based on load
      • Prevents gouging, damaging or burning stock
      • Provides consistent finish even with varying grain pattern and density
      • Greatly increases abrasive planing and dimensioning speed
    • Flatness Guarantee: Precision-flattened steel conveyor bed reinforced with four steel cross sections for no “flex” in conveyor, guaranteeing flatness to less than .010″ across the width of the sander
    • Abrasive conveyor belt offers the best grip for raw wood, giving you the ability to accommodate stock that is much shorter or thinner
    • Patented Abrasive Attachment System effectively tensions the abrasive wraps, preventing loose abrasive and overlap
    • Easiest access to abrasive fastening system of any drum sander! Extra wide space to access fasteners to eliminate need for special tools
    • Self-cooling drum prevents overheating and extends abrasive life
    • Tension rollers are adjustable in height and hold down pressure, eliminating snipe
    • Excellent dust extraction as dust cover is formed to shape of drum Metal, not plastic, is formed to maximize air flow and dust extraction
    • Heavy-duty cast iron construction for strength, rigidity and reduced vibration

      Additional Details

      Flatter: Produces near-finish results and eliminates primary hand sanding

      Nylon: Scuff sand and defuzz stock

      Wire: Pull the soft grain out from softwoods or clean reclaimed lumber

      Drum: Dimension or finish sand flat stock

      Simple alignment feature Just one nut will adjust the conveyor to parallel the sanding head, making aligning the conveyor to the sanding head fast and easy. Indexed alignment setting Has an indexed alignment setting for narrow and wide stock. When sanding stock wider than 19″, the index lever will properly adjust the conveyor for flawless wide sanding. Easy height adjustments A thrust bearing below the handle and a nut positioned above prevents the drum from moving out of the set position while sanding. No backlash or slop in the height adjustment mechanism allowing easier and smoother height adjustments. Extra-wide conveyor to properly support stock over 19″ wide. The conveyor table is 22″ wide to add support to the work piece. Excellent dust extraction, as metal dust cover is formed to shape of drum. Tension rollers are adjustable in height and hold down pressure, eliminating snipe. Heavy-duty cast iron construction for strength, rigidity and reduced vibration.

      Specifications

      Sanding Capacity

      • Maximum Width (in): 38″ (two passes)
      • Minimum Length (in): 5-½″
      • Maximum Thickness (in): 4″ (Varies With Application)
      • Minimum Thickness (in): 1/32″


      Machine Specs

      • Dimensions (H x W x D): 24″ x 40″ x 24″
      • Drum Speed: 1740 RPM
      • Dust Hood: 1 – 4″ Vacuum port, min. 600 CFM Recommended
      • Conveyor Motor: 43in.-lb torque, direct drive D.C. motor, ranged variable 0-10 FPM
      • Drive Motor (TEFC): 1-¾
      • Power Requirements: 110V 15 Amp
      • Net Weight: 264 lbs
      • Shipping Weight: 371 lbs
      • Shipping Dimensions (L x W x H): 43″ x 16″ x 24″
      Manuals
      What Our Experts Think
      • Combines drum sanding and brush profiling in one machine.

      • Handles up to 19″ in a single pass or 38″ in two passes.

      • Heavy-duty cast iron construction reduces vibration.

      • Interchangeable heads allow sanding, finishing, and cleaning reclaimed lumber.

      • Ideal for shops needing versatile panel preparation and surface finishing.

      Q&A

      Q: What width can it handle?
      A: Up to 38″ in two passes, 19″ in a single pass.

      Q: What thickness can it sand?
      A: Maximum around 4″, minimum 1/32″.

      Q: What motor does it use?
      A: 1¾ HP, 110V motor.

      Q: Can it clean reclaimed lumber?
      A: Yes, wire and nylon brush heads are included.

      Q: Is it suitable for finishing panels?
      A: Yes, the combination of drum and brush heads provides smooth, uniform surfaces.

      Maintenance Tips
      • Keep conveyor bed clean and level.

      • Check alignment to ensure accurate feed.

      • Inspect drum and brush heads for wear.

      • Adjust hold-down rollers for consistent contact.

      • Maintain dust extraction for safety and performance.
