Maxx Cold Dual Tower, 2 Tap Beer Dispenser, 73"W, 17.3 cu. ft., 3 Barrels/Kegs (490L) Storage Capacity, in Black with Stainless Steel Top - MXBD72-2BHC
This 73 inch wide Maxx Cold X-Series Beer Tower Dispenser is engineered for durable usage, efficient performance, and easy cleaning. It accommodates 3 barrel/keg, providing up to 17.3 cubic feet (490L) of storage capacity. This beer tower is equipped with two 3” (77mm) diameter stainless steel insulated beer tower dispensers which can accommodate for two different liquids. This tower beer dispenser is ideal for pubs, bars, breweries, catering services, banquet halls or special events and parties requiring a draft brew. The exterior of the unit is constructed of black powder-coated steel topped with stainless-steel, while the interior of the cabinet is crafted in sanitary white coated steel paired with a stainless floorplate. This unit is fully insulated with 2” (50 mm) CFC-free polyurethane on both walls and doors. The standard 3-inch (77 mm) polished stainless-steel draft tower dispensers, which are mounted to the top center counter, are cooled by continuous cold air circulation to maintain tap temperature that reduces foam when dispensing and can easily fill pint beer glasses, frosted beer mugs and pitchers. Premium features on this model include a self-contained forced air refrigeration system which cools the base cabinet and tower to optimize temperature throughout your commercial operations. The solid-state digital control system is designed with LED temperature display. This beer tower dispenser is engineered to facilitate maintenance and maneuvering by the operator, with an easy to clean slide-out condensing unit, recessed drawer handles (with locks) and four (4) swivel casters (two of which come with brakes). The dispenser is equipped with integrated condensate evaporator, meaning no drain line connection is needed. Operation requires CO2 tank and regulator (not included).
Features
- Accommodates 3 barrel/kegs with storage capacity of 17.3 cubic feet (490L)
- Two 3” (77mm) diameter stainless steel insulated beer tower dispenses four different liquids
- Interior is constructed of sanitary white coated steel with a stainless floorplate
- Exterior is black coated steel with a stainless steel top
- 2” (50mm) CFC-free polyurethane insulated walls and doors
- Self-contained forced air refrigeration system cools the base cabinet and tower
- Slide out condensing unit for easy maintenance
- Epoxy coated evaporator coils to resist corrosion
- Easy to grip recessed drawer handles with locks
- Adjustable heavy duty wire shelves (2 per section/door)
- Six 4” casters included, two (2) with brakes (Smaller casters available for ADA Compliance)
- Holding temperature of 34°F and 41°F (1⁰C to 5⁰C)
- Available in 120V/60Hz/1pH and International voltage options
- Environmentally friendly R134A refrigerant
Specifications
| Adjustable Shelves |
No |
| Adjustable Temperature Control |
Yes |
| Amperage |
3A |
| Assembled Dimensions (LxWxH) |
24.40" x 73.07" x 55.98" |
| Assembled Weight (lb) |
351.0 |
| Assembly Required |
Yes |
| Batteries Required |
No |
| Capacity |
3 Kegs |
| Caster Size |
4" |
| Casters |
Yes |
| Color |
Black |
| Control Type |
Digital |
| Cooling System |
Compressor |
| Cord Length |
72" |
| Cordless |
No |
| Defrost System Type |
Automatic / Frost-Free |
| Depth - Door Open 90° |
43" |
| Depth - Excluding Door |
29.90" |
| Depth - Excluding Handles |
29.90" |
| Dishwasher Safe Components |
Yes |
| Door Color/Finish |
Black |
| Door Material |
Powder Coated Steel |
| Door Swing Orientation |
French-Door |
| Electric |
Yes |
| First Zone Maximum Temperature |
41° |
| First Zone Minimum Temperature |
33° |
| Freezer Type |
No Freezer |
| Ice Maker Included |
No |
| Included Components |
Refrigerator, Instruction Manual, Casters |
| Installation Type |
Freestanding |
| Integrated Lock |
Yes |
| Material |
Powder Coated Steel |
| Number of Doors |
3.0 |
| Number of Items |
1.0 |
| Outdoor Use |
No |
| Plug Type |
NEMA 5-15P |
| Portable |
No |
| Refrigerant Type |
R-290a |
| Size |
73" |
| Temperature Range |
33° - 41° |
| Temperature Zones |
1.0 |
| Undercounter |
No |
| Voltage |
120V |
| Volume Capacity |
490L |
| Warranty |
1 Year Parts & Labor + 5 Year Compressor (Part Only) |
| Water Dispenser |
No |
| Wattage |
360W |
| Case Pack Dimensions |
84" x 40" x 31" |
| Case Pack Weight |
373.0 |
What Our Experts Think
-
17.3 cu. ft. Capacity – Large storage space for up to three kegs, making it ideal for high-demand bars, pubs, or restaurants.
-
Dual Tower with 2 Taps per Tower – Offers the ability to serve four different beers simultaneously, improving customer service and efficiency.
-
73" Width – Provides a spacious yet compact design, allowing easy access while optimizing space for keg storage.
-
Durable Black with Stainless Steel Top – Sleek, modern, and built to withstand the demands of busy commercial environments.
-
Reliable Cooling – Maintains optimal beer temperatures for a crisp, fresh taste, ensuring quality and customer satisfaction.
Q&A
Q: What are the main features of the Maxx Cold Dual Tower Beer Dispenser?
A: The Maxx Cold MXBD72-2BHC features a 73" width, 17.3 cu. ft. storage capacity, and can hold up to 3 barrels/kegs (490L). It has a black exterior with a stainless steel top, designed for high-efficiency beer dispensing in commercial environments.
Q: How much keg storage does the Maxx Cold Beer Dispenser offer?
A: It can store up to 3 barrels/kegs with a total capacity of 490L, ideal for high-volume beer dispensing in bars or restaurants.
Q: Is the Maxx Cold Beer Dispenser energy-efficient?
A: Yes, it is designed to operate efficiently, maintaining the right temperatures for beer storage and dispensing while helping to reduce energy consumption.
Q: Can the Maxx Cold Beer Dispenser be used in commercial settings?
A: Yes, its robust design and reliable performance make it ideal for use in high-traffic commercial environments like bars, pubs, and restaurants.
Q: Is the Maxx Cold Beer Dispenser easy to clean?
A: Yes, the black exterior and stainless steel top make it easy to clean and maintain, ensuring a hygienic environment for dispensing beer.
Maintenance Tips
-
Clean beer lines regularly to prevent any buildup of residue and ensure fresh beer quality.
-
Wipe down the exterior with a mild, non-abrasive cleaner to maintain cleanliness and appearance.
-
Inspect and clean the faucets to prevent clogging and ensure smooth beer dispensing.
-
Check the seals around the doors to ensure they form a tight seal, preventing cold air loss.
-
Clean the condenser coils periodically to avoid dust buildup and maintain efficient cooling.
-
Monitor the temperature regularly to ensure the beer is dispensed at the ideal temperature.
