MRCOOL VersaPro 2nd Gen 48K BTU, 4 Ton, 16 SEER2 Central Ducted Heat Pump Condenser - MVP-48-HP-C-230A00-O
The 4 Ton MRCOOL® VersaPro® Central Ducted Heat Pump Condenser offers a dependable and efficient solution for year-round heating and cooling. Designed with durability and modern technology, this unit provides consistent comfort in all seasons. With a variable-speed 48k capacity, the VersaPro® achieves a SEER2 rating of 16 and an HSPF4 rating of 8.5. Paired with the MRCOOL® VersaPro® Central Ducted Air Handler, it creates a complete and reliable system tailored to your home’s needs. The DC inverter technology ensures quiet operation and optimized energy use, making it an excellent upgrade from older, less efficient systems. You’ll also receive the MRCOOL® Smart thermostat, giving you complete control over your home’s temperature with ease.
The VersaPro® condenser utilizes R-454B refrigerant, a more environmentally friendly alternative to traditional refrigerants. Its durable painted galvanized steel construction is built to withstand the elements, while the compact side-discharge design makes installation easier in tight spaces. Maintenance is simplified with the built-in self-diagnostics system, which helps identify issues quickly and reduce service calls. To ensure peace of mind, the VersaPro® comes with a 10-year warranty covering the compressor and parts. This long-term protection ensures reliable performance and safeguards your investment. Choose the 4 Ton MRCOOL® VersaPro® Central Ducted Heat Pump Condenser for an efficient, reliable way to maintain home comfort.
Specifications
Dimensions |
16.34" D x 38.39" H x 38.58" W |
SEER2 |
16 |
EER2 |
10 |
HSPF-4 |
8.5 |
HSPF-5 |
7.2 |
CFM |
3037.1 |
Tonnage |
4 |
Cooling Capacity (BTU) |
48000 |
Heating Capacity (BTU) |
48000 |
Voltage (V) |
208-230 |
Phase |
1 |
Cycle |
60 |
Max Fuse Breaker (A) |
40 |
Min Circuit Ampacity (A) |
36 |
Color |
gray |
Refrigerant Type |
R454B |
Refrigerant Volume (OZ) |
134.04 |
Decibel Rating (DBA) |
65 |
Liquid Line Size |
3/8 |
Suction Line Size |
3/4 |
WIFI Compatibility |
Yes |
APP Compatibility |
Yes |
ETL Certified |
Yes |
Energy Star Certified |
Yes |
AHRI Certified |
Yes |
Base Parts Warranty |
10 Years |
Base Compressor Warranty |
10 Years |
Contains Electronics |
Yes |
Contains Chemicals |
Yes |
Contains Compressed Gas |
Yes |
Net Weight (Lbs) |
192.9 |
Gross Depth (In) |
19.68 |
Gross Height (In) |
42.52 |
Gross Width (In) |
45.08 |
Gross Weight (Lbs) |
224.21 |
What our Experts Think
-
Powerful Performance – With 48K BTU and 4-ton capacity, this condenser efficiently handles cooling and heating for larger homes.
-
Energy Savings – Rated at 16 SEER2, it provides reliable efficiency to reduce long-term utility costs.
-
All-Season Comfort – Heat pump design ensures dependable cooling in summer and heating in winter.
-
Built to Last – Heavy-duty components and durable construction maximize lifespan and performance.
-
System Ready – Specifically designed to integrate with MRCOOL VersaPro 2nd Gen central ducted air handlers for a complete HVAC solution.
Q&A
Q: What is the cooling and heating capacity?
A: This VersaPro 2nd Gen condenser delivers 48,000 BTU (4 ton) cooling and heating capacity for medium to large residential spaces.
Q: What is the efficiency rating?
A: It operates at 16 SEER2, providing reliable energy efficiency that meets modern HVAC standards.
Q: Is this condenser compatible with ducted systems?
A: Yes, it is designed specifically for use with MRCOOL VersaPro central ducted air handlers.
Q: Does it provide both heating and cooling?
A: Yes, it’s a heat pump condenser, offering all-season comfort by delivering both cooling in summer and heating in winter.
Q: Who is this best suited for?
A: Ideal for homeowners or contractors looking for a durable, high-performance 4-ton central split system solution.
Q: Does this package include the air handler?
A: No, this listing is for the condenser unit only; a compatible VersaPro air handler must be purchased separately.
Maintenance Tips
-
Keep condenser coils clean and free of dirt, leaves, and outdoor debris.
-
Trim vegetation at least 2 feet around the unit for proper airflow.
-
Inspect refrigerant lines and insulation for wear or leaks.
-
Check fan blades and motor for balance and smooth operation.
-
Clean or replace air filters regularly in the connected air handler.
-
Schedule annual HVAC servicing to ensure peak efficiency and long-term reliability.
