Osburn Matrix 2700 Wood Insert - OB02700
The Matrix 2700 Wood Insert from Osburn
Inspired by nature, the Matrix 2700 insert is a fusion of traditional style and technological innovation. Located in the heart of your living space, the generous viewing area of the Matrix 2700 will invite you to sit back, relax, and take in the calm and warmth of its flames. Eco-savvy consumers will appreciate its efficient combustion, quality performance, and classic beauty.
This unit comes standard with a cast iron faceplate and heat-activated blower. Customize the look of this non-catalytic appliance by choosing from a black or brushed silver-plated door overlay and fire screen.
Specifications
| Fuel type |
Dry cordwood (16" recommended) |
| Recommended heating area-ft² |
750 - 2,200 |
| Overall firebox volume-ft³ |
2.5 |
| EPA loading volume-ft³ |
1.94 |
| Maximum burn time |
8 h |
| Maximum heat output-dry cordwood |
80,000 BTU/h (23.4 kW) |
| Overall heat output rate < |
12,700 BTU/h (3.72 kW) to 60,700 BTU/h (17.79 kW) |
| Average overall efficiency (dry cordwood) |
64 % (HHV) |
68 % (LHV) |
| Optimum overall efficiency |
70 % |
| Optimum heat transfer efficiency |
68 % |
| Average particulate emissions rate |
1.2 g/h |
| Average CO |
98 g/h |
Manual
What Our Experts Think
-
Exceptional Heating Power: Ideal for large spaces, offering high heat output and consistent warmth throughout your home.
-
Eco-Friendly Efficiency: Advanced combustion technology minimizes emissions while maximizing heat output, making it an environmentally responsible choice.
-
Modern & Elegant Design: The sleek, contemporary look of the Matrix 2700 complements any room, enhancing both style and function.
-
User-Friendly: Easy-to-use controls and adjustable air intake for customized comfort and heat management.
-
Long-Lasting Durability: Built to withstand the test of time with durable materials, requiring minimal maintenance.
-
Cost-Effective: Efficiently reduces heating costs while providing a reliable, sustainable heating solution.
Q&A
Q: What type of wood does it burn?
A: It burns seasoned hardwood for optimal performance and heat efficiency.
Q: How long does it burn per load?
A: It offers up to 10 hours of burn time, depending on wood type and burn conditions.
Q: Does it come with a blower?
A: Yes, it includes a 144 CFM blower for efficient heat distribution.
Q: What are the insert's dimensions?
A: Approx. 35” W x 25 ⅝” H x 22 ¾” D.
Q: Does it qualify for tax credits?
A: Yes, it qualifies for federal biomass stove tax credits.
Maintenance Tips
-
Clean Ashes Regularly – Empty the ash pan frequently to prevent buildup and maintain efficient airflow.
-
Inspect Gaskets – Check door and glass gaskets for wear and replace if necessary to maintain a tight seal.
-
Clean the Glass – Use a wood stove glass cleaner or a damp cloth with ash to keep the glass clean and free from soot.
-
Chimney Sweeping – Clean the chimney at least once a year to remove creosote buildup and ensure safe operation.
-
Firebrick Care – Inspect firebricks for damage or wear, and replace them as needed to retain heat efficiently.
-
Burn Dry Wood – Only use dry, seasoned wood to reduce creosote buildup and improve combustion efficiency.
