Osburn Matrix Wood Stove with Blower - OB02032
The Matrix Wood Stove with Blower from Osburn
With the same sleek, modern style and vastly improved performance, the Matrix wood-burning stove will certainly bring a European touch to your home. Let the Matrix wood stove provide you the warmth, safety, and coziness needed during these cold winters
You can now personalize your device with the steel or soapstone top and side panel options from a local Quebec City mine, reminding us of the richness of our natural resources. Logs will easily fit under the large firebox, making the Matrix a practical and stylish heater. The Matrix is equipped with a 130 CFM fan to ensure optimal heat distribution. Enjoy the comfort of winter more than ever before!
Specifications
| Fuel type |
Dry cordwood (16" recommended) |
| Recommended heating area-ft² |
500 - 2,100 |
| Overall firebox volume-ft³ |
2.4 |
| EPA loading volume-ft³ |
1.95 |
| Maximum burn time |
8 h |
| Maximum heat output-dry cordwood |
75,000 BTU/h (22.0 kW) |
| Overall heat output rate < |
14,200 BTU/h (4.16 kW) to 44,500 BTU/h (13.04 kW) |
| Average overall efficiency (dry cordwood) |
72 % (HHV) |
77 % (LHV) |
| Optimum overall efficiency |
79 % |
| Optimum heat transfer efficiency |
76 % |
| Average particulate emissions rate |
2.3 g/h |
| Average CO |
69 g/h |
Resources
Manual
Osburn Matrix Wood Stove with Blo
Osburn Matrix Wood Stove with Blower
What Our Experts Think
-
High Heating Efficiency: Ideal for medium to large rooms, offering superior warmth with powerful heat distribution from the integrated blower.
-
Eco-Friendly Combustion: Advanced technology reduces emissions, providing clean and efficient burning for a greener home.
-
Stylish & Functional Design: Sleek modern design with a blower system to enhance heat circulation, keeping your space comfortable.
-
User-Friendly Features: Simple controls and adjustable air intake for easy customization of heat output.
-
Durable Construction: Built with high-quality materials, ensuring reliability and long-lasting performance.
-
Cost-Effective: Efficient heating that lowers energy bills while providing sustainable warmth throughout the colder months.
Q&A
Q: What type of wood does it burn?
A: It burns seasoned hardwood for optimal efficiency and heat output.
Q: How long does it burn per load?
A: The stove provides up to 8 hours of burn time, depending on wood type and burn conditions.
Q: What are the stove's dimensions?
A: Approx. 29 ½” W x 23 ⅞” H x 23” D.
Q: Does it qualify for tax credits?
A: Yes, it qualifies for federal biomass stove tax credits.
Maintenance Tips
-
Clean Ashes Regularly – Remove ashes to ensure proper airflow and maintain combustion efficiency.
-
Inspect Gaskets – Check door and glass gaskets for wear and replace if necessary to maintain an airtight seal.
-
Clean the Glass – Use a non-abrasive cleaner or damp cloth with ash to remove soot and keep the glass clear.
-
Chimney Cleaning – Sweep the chimney at least once a year to prevent creosote buildup and ensure safe operation.
-
Check Firebricks – Inspect firebricks for cracks and replace if damaged to maintain heat retention.
-
Blower Maintenance – Clean the blower periodically to ensure it operates efficiently and circulates heat effectively.
-
Use Dry Wood – Burn only dry, seasoned wood to reduce creosote buildup and maximize efficiency.
