U.S. Motors NAL1034 HVAC Single Phase ODP Hub/Stud Motor - NAL1034
The U.S. Motors NAL1034 is an HVAC single phase ODP hub/stud motor ideal for various applications. This motor operates efficiently at one-third horsepower and provides a speed of eighteen hundred RPM. It features a continuous duty operation and is suitable for HVAC systems that require reliable performance.
Product Highlights
This motor is designed for performance in HVAC applications with its robust construction and reliable specifications.
Features
- 1/3 hp motor
- 1800 RPM speed
- Continuous duty rating
Specifications
| Brand |
U.S. Motors |
| Part Number (MPN) |
113631638 |
| Mounting |
Hub/Stud |
| Motor Application |
HVAC |
| Frequency (Hz) |
50/60 Hz |
| Poles |
4 |
| Duty |
Continuous Duty |
| Full Load Amps |
5.7 A |
| Number of Speeds |
3 |
| Full Load RPM |
1625 RPM |
| Service Factor |
1 |
| Enclosure |
ODP (Open Drip Proof) |
| Phase |
Single Phase |
| Frame |
48Y |
| Thermal Protection |
Automatic Reset |
| Voltage Rating |
115 V |
| Weight |
12.74 lb |
| EAN or UPC |
786382114459 |
What our Experts Think
-
Efficient Performance: The U.S. Motors NAL1034 HVAC motor is designed for optimal efficiency, ensuring reduced energy consumption while maintaining high performance.
-
Durable & Reliable: Built with quality materials, this motor offers longevity, even in demanding HVAC systems.
-
Versatile Use: Ideal for various HVAC applications, making it a versatile choice for contractors and service professionals.
-
ODP Design: The open drip-proof (ODP) design offers superior protection against moisture and debris, ensuring smooth operation in diverse environments.
-
Easy Installation: The hub/stud configuration simplifies installation, saving time and effort on the job.
-
Proven Quality: Manufactured by U.S. Motors, a trusted brand in the industry, known for producing high-quality, dependable motors.
Q&A
Q: What applications is the U.S. Motors NAL1034 motor suitable for?
A: This motor is designed for HVAC applications, including use in fan and blower systems where continuous air-over cooling is required.
Q: What are the key specifications of the NAL1034 motor?
A: The motor delivers 1/3 horsepower at 1625 RPM, operates on 115V single-phase power, and features a 48Y frame size. It has an Open Drip Proof (ODP) enclosure, making it suitable for clean, dry indoor environments.
Q: What are the mechanical specifications of the NAL1034 motor?
A: The motor includes a 5/8" diameter x 8.4" shaft, ball bearings, and a service factor of 1.0. It is designed for continuous duty and has an automatic thermal protector with reset capability.
Q: What mounting options are available for the NAL1034 motor?
A: The motor features a hub and stud mounting configuration, with an adjustable hub length adapter included, providing flexibility for various installation requirements.
Q: Is this motor compatible with variable frequency drive (VFD) applications?
A: Yes, the NAL1034 motor is compatible with VFD applications, offering flexibility in speed control for various HVAC systems.
Maintenance Tips
-
Regular Inspections: Check for signs of wear or damage to the motor and its components.
-
Keep Clean: Ensure the motor is free from dust and debris to maintain efficient operation.
-
Lubrication: Follow the manufacturer's guidelines for bearing lubrication to prevent wear.
-
Monitor Performance: Listen for unusual noises and check for vibrations that may indicate issues.
-
Electrical Connections: Inspect wiring and connections for signs of corrosion or loose connections.
