U.S. Motors U25P1DC General Purpose Three Phase, TEFC Unimount NEMA Premium Efficient - IE3, C-Face Footed Motor - U25P1DC
The U.S. Motors U25P1DC is a general-purpose three-phase motor designed for various applications. Its robust construction and high efficiency make it suitable for pumps, fans, compressors, and other equipment. This motor operates at twenty-five horsepower and has a rated speed of three thousand six hundred rpm, ensuring reliable performance in demanding environments.
Product Highlights
Ideal for industrial use, this motor features a continuous duty cycle and is suited for horizontal mounting applications.
Features
- TEFC enclosure for protection against dust and moisture.
- Dual voltage options of 208-230/460 volts.
- Class F insulation for high-temperature environments.
Specifications
| Operating Frequency |
50/60 Hz |
| Full Load Efficiency |
91.7% |
| Full Load Amps |
65-57/28.4 |
| Poles |
2 |
| Duty Type |
Continuous Duty |
| Frame Size |
284TC |
| Weight |
250 lb |
| Material |
Aluminum |
| Brand |
U.S. Motors |
| MPN |
U25P1DC |
What our Experts Think
-
High-Efficiency Performance: The U.S. Motors U25P1DC provides 25 HP at 3600 RPM with a NEMA Premium Efficiency rating (IE3), ensuring optimal energy use and reduced operational costs.
-
Durable Construction: Featuring a Totally Enclosed Fan Cooled (TEFC) design, it is built to protect against dust, moisture, and other contaminants, offering long-lasting reliability in harsh environments.
-
Versatile Application: Ideal for a wide range of industrial applications such as HVAC systems, compressors, and pumps, where consistent and powerful performance is needed.
-
Easy Integration: Designed with a C-Face footed mount for simple and secure installation, minimizing downtime during setup.
Q&A
Q: What applications is the U.S. Motors U25P1DC motor suitable for?
A: This motor is ideal for industrial applications like pumps, fans, compressors, and material handling equipment.
Q: What are the key features of the U25P1DC motor?
A: It is a 25 HP motor with a 3600 RPM rating, featuring a Totally Enclosed Fan Cooled (TEFC) design, NEMA Premium Efficiency (IE3) rating, and a 91.7% full load efficiency.
Q: What are the voltage and phase specifications for this motor?
A: The motor operates on 3-phase power with dual voltage options: 208-230/460V at 60Hz.
Q: What is the motor's duty rating and service factor?
A: The U25P1DC is rated for continuous duty with a service factor of 1.25, allowing it to handle occasional overloads.
Q: What are the physical dimensions and mounting options?
A: It has a 284TC frame size and a C-face footed mounting design, offering flexibility for various installations.
Q: Is this motor compliant with industry standards?
A: Yes, it meets NEMA Premium efficiency standards and is CE, CSA, and UL listed for high performance and safety.
Maintenance Tips
-
Regular Inspection: Check for unusual vibrations, overheating, or noise. Ensure the motor operates smoothly without any irregularities.
-
Keep Clean: Regularly clean the motor to remove dust and debris. Ensure the motor vents remain clear to maintain proper ventilation and cooling.
-
Lubricate Bearings: Apply the recommended lubricant to the bearings as per the manufacturer's instructions to ensure smooth operation.
-
Check Electrical Connections: Inspect all wiring and connections for signs of wear or corrosion. Tighten and clean connections as necessary to ensure optimal electrical performance.
-
Monitor Load & Voltage: Ensure the motor is not overloaded and that the voltage is within the specified range to prevent potential damage.
-
Proper Storage: If the motor is not in use, store it in a dry, clean, and well-ventilated area to prevent moisture-related damage.
